302

Compact Regulators 302 Series



Ordering Information

Type   :   Single Stage

Inlet Connection   :   1/4” F. NPT

Outlet Connection   :   3/8” F. NPT

Orifice Size   :   #50 Drill

Factory Delivery Pressure   :   11” w.c. at 100 PSIG Inlet

Adjustment Range   :   9” to 13” w.c.

Bonnet Vent Position   :   Small Vent Above Inlet

Vapor Capacity BTU/ hr. Propane*   :   125,000



*Maximum flow based on 25 PSIG inlet and 9” w.c. delivery pressure.
