50A (2")



Pipe Size (inside diameter)   :   32 mm. 40 mm. 50 mm. (Ball Valve)

Power   :   DC 24V

Valve   :   Ball Valve use

Gear Ratio   :   1050: 1

Opening/ Closing Time   :   12 sec.

Opening and Shutting Angel   :   90 Degree

Gear Materials   :   S45C

Body Materials   :   Body: Aluminum/ Case: Stainless/ Clamp : Aluminum

Operational Temperature   :   -10 ◦C- 40 ◦C

Relative Humidity   :   0-85% Rh

Installation   :   Clamping Bolt

Dimensions (WxHxD)   :   Ø 133x239x223 mm. (32A, 40A, 50A)

Weight (g)   :   3.3 kg. (32A), 3.2 kg. (40A), 3.1 kg. (50A)
